    Copper Nickel Pipes and Tubes , ASTM B111 C70400 C70600,ASTM B288, ASTM B688

    Ask Lasest Price
    Brand Name : YUHONG
    Model Number : Copper Nickel Pipes and Tubes ASTM B111 C71500 C70600,ASTM B288, ASTM B688.
    Certification : ABS, BV, ISO, ASTM, SGS
    Payment Terms : L/C, T/T
    Delivery Time : 7DAYS
    • Product Details
    • Company Profile

    Copper Nickel Pipes and Tubes , ASTM B111 C70400 C70600,ASTM B288, ASTM B688

    Copper Nickel Pipes and Tubes , ASTM B111 C70400 C70600,ASTM B288, ASTM B688

    ASTM B111/ B111M : Standard Specification for Copper and Copper-Alloy Seamless Condenser Tubes and Ferrule Stock

    Copper or Copper Alloy UNS No.Description
    C10100Oxygen-free electronic
    C10200Oxygen-free without residual deoxidants
    C10300Oxygen-free, extra low phosphorus
    C10800Oxygen-free, low phosphorus
    C12000Phosphorized, low residual phosphorus
    C12200Phosphorized, high residual phosphorus
    C14200Phosphorized, arsenical
    C19200Phosphorized, 1 % iron
    C23000Red Brass
    C28000Muntz Metal
    C44300Admiralty Metals, B, C, and D
    C44400
    C44500
    C60800Aluminum Bronze
    C61300
    C61400Aluminum Bronze, D
    C68700Aluminum Brass, B
    C7040095-5 Copper-Nickel
    C7060090-10 Copper-Nickel
    C7062090-10 Copper-Nickel—Welding Grade
    C7100080-20 Copper-Nickel
    C7150070-30 Copper-Nickel
    C7152070-30 Copper-Nickel—Welding Grade
    C71640Copper-nickel-iron-manganese
    C72200


    BRASS COPPER SEAMLESS BOILER TUBE ASTM B111 O61 C44300 C68700 C71500 Used for Air Condenser PASSED 3.2MTC INSPECTION

    TESTING: ET; HT; Flattening Test; Expansion Test, Mercurous Nitrate Test; Ammonia Vapor Test; Chemical Analysis; Microscopical Examination; Tension Testing.

    Cupro Nickel Rods 90/10 and 95/5

    Cupro Nickel Rods For 90/10

    Chemical Properties
    Pb0.05 Max.
    Fe1.00 - 1.80
    Mn1.00 Max.
    Zn1.00 Max.

    Cu + Ag Remainder Ni + Co 9.00 - 11.00

    Mechenical Properties
    Light Drawn
    Flattening TestReqd. (After 'O')
    U.T.S. ksi45.00 Min
    Y.S. at 0.5% Ext. ksi35.00 Min.

    Expansion Test 30% at 60 degree Reqd. (After 'O')

    Annealed Temper
    Flattening TestReqd.
    Grain Size at 75 X mm Avg.0.010 - 0.045
    U.T.S. ksi40.00 Min.
    Y.S. at 0.5% Ext. ksi15.00 Min.

    Expansion Test 30% at 60 degree Reqd.

    Cupro Nickel Rods For 95/5

    Chemical Properties
    Sn0.10 Max.
    Pb0.05 Max
    Ni4.00 - 5.00
    Fe0.10 Max.
    Mn0.25 Max.
    As0.10 Max.
    Cu + Ag95.00 - 96.000
    Sb0.01 Max.
    Bi0.0025 Max.

    Oxygen (O2) 0.08 Max.

    Mechenical Properties
    Annealed
    U.T.S. MPa216 - 275 (Strip cut from Ring Tube)
    %Elongation at 5.65Sq.Rt So G.L.40.00 Min. (Strip cut from Ring Tube)
    Flattening TestReqd.
    Bend TestReqd. (180 degree close)


    Cupro Nickel Pancake Coils
    Copper-nickel brake tubing provides superior reliability and assures both manufacturers and vehicle owners improved durability for effective long-life functioning of the brake system.Coils Available in 5 mtr, 10 mtr & 15mtrs.

    Copper Nickel Pipes and Tubes , ASTM B111 C70400 C70600,ASTM B288, ASTM B688
