ASTM B622 C22 SMLS Tube NO6022 Hastelloy Nickel Alloy Steel Tube

ASTM B622 C22 SMLS Tube NO6022 Hastelloy Nickel Alloy Steel Tube

YuHong supplies ASTM B622 C22 SMLS TUBES, the material is a a nickel-molybdenum-chromium super-alloy with an addition of tungsten designed to have excellent corrosion resistance in a wide range of severe environments. This nickel alloy is resistant to the formation of grain boundary precipitates in the weld heat-affected zone, thus making it suitable for most chemical process application in an as welded condition.

Hastelloy C22, is a versatile austenitic nickel-chromium-molybdenum-tungsten alloy with enhanced resistance to pitting, crevice corrosion and stress corrosion cracking. The high chromium content provides good resistance to oxidizing media while the molybdenum and tungsten content give good resistance to reducing media.

This nickel steel alloy also has excellent resistance to oxidizing aqueous media including wet chlorine and mixtures containing nitric acid or oxidizing acids with chlorine ions. Other corrosives Hastelloy C-22 has resistance to are oxidizing acid chlorides, wet chlorine, formic and acetic acids, ferric and cupric chlorides, sea water, brine and many mixed or contaminated chemical solutions, both organic and inorganic. This nickel alloy also offers optimum resistance to environments where reducing and oxidizing conditions are encountered in process streams.

Specification Of ASTM B622 UNS NO6022 SMLS Tube

ASTM/ ASME Specification	ASTM B619/ ASME SB 619, ASTM B622 / ASME SB 622 Standard Specification for Seamless & Welded Superheater, Condenser, Hydraulic, Boiler and Heat-Exchanger Tubes
Shapes	Hastelloy UNS N06022 Round, Rectangular, Square, Hydraulic, Straight, "U" Shape, Coiled, Honed Tubes, Pan Cake Coils
Manufacturing Type	Seamless / ERW / Welded / Fabricated / CDW / CDS / DOM / CEW / 100% X Ray Welded
Thickness Range	SCH 5, SCH10, SCH 40, SCH 80, SCH 80S, SCH 160, SCH XXH, SCH XXS, SCH XS
Swg & Bwg	10 Swg., 12 Swg., 14 Swg., 16 Swg., 18 Swg., 20 Swg.
Standard	SUS, JIS, AISI, ASTM, GB, DIN, EN
Delivery Condition	Annealed and Pickled (AP), Polished, Bright Annealed (BA), Cold Drawn, MF
Value Added Services	Cutting/Beveling/Threading/Draw & Expansion as per required Size & Length/Ultrasonic Testing/Annealed & Pickled Bending/Destructive and Non Destructive
END	Plain End, Beveled End, Treaded Hastelloy Alloy C22 Tube
Processing Service	Bending, Welding, Decoiling, Punching, Cutting, Moulding
Technique	C22 Hastelloy Cold drawn, Cold rolled, Hot rolled, Extrusion Tube
Marking	Specification/Material Grade/Nominal Size/Schedule or Wall Thickness/Method of Manufacturing (Seamless / Welded)/Heat Number/Manufacturer’s Name or Custom Logo - on request
	Marked Sample: ASTM B622 UNS N06022 Seamless 113.60 mm OD x 6 mm W.T. HEAT No. xxxxxx
Test Certificate	DFARS compliant
	EN 10204/3.1B, EN 10204 3.1 and EN 10204 3.2 Material Test Certificates (MTC)
	HS Code Commercial Invoice
	Raw Materials Certificate
	Moisture testing
	Fumigation Certificates
	100% Radiography Test Report
	Heat Treatment Charts
	Third Party Inspection Report
	Surface roughness measurement
	Manufacturer Test Certificate
	Laboratory Test Certificate from Govt. Approved Lab
Alloy NW 6022 Tubing Packaging	Packed in PE Fabric Bundles or ply wooden box wrapped in plastic or Standard seaworthy export packing or as per customers' request
Port	Ningbo or Shanghai, China

Wall Thickness Of ASTM B622 UNS NO6022 SMLS Tube

Types of Monel 600 Tube	Out diameter (OD)	Wall thickness	Length
NB Sizes (in stock)	1/8” ~ 48”	SCH 5 / SCH 10 / SCH 40 / SCH 80 / SCH 160	Upto 6 Meters
Monel 600 Seamless Tube (Custom Sizes)	5.0mm ~ 203.2mm	As per requirement	Upto 6 Meters
Monel 600 Welded Tube (in Stock + Custom Sizes)	5.0mm ~ 1219.2mm	1.0 ~ 15.0 mm	Upto 6 Meters

Chemical Composition Of ASTM B622 UNS NO6022 SMLS Tube

Element	Content, %
Nickel [Ni]	balance
Chromium [Cr]	20-22.5
Iron [Fe]	2-6
Manganese [Mn]	0.5Max
Carbon [C]	0.15 Max
Silicon [Si]	0.08 Max
Sulfur [S]	0.02 Max

Mechanical Properties Of ASTM B622 UNS NO6022 SMLS Tube

Density	Melting Range	Yield Stress (0.2%Offset)	Tensile Stress	Elongation
8.69 g/cm3	1399 °C (2550 °F)	Psi - 45000 , MPa - 310	Psi - 1,00,000 , MPa - 690	0.45
