ASTM A179 Al Aleta Embedded Finned Tube G-Type Para Calderas

ASTM A179 + Al Aleta Embedded Finned Tube G-Type Para Calderas

YUHONG Group offers ASTM A179 Embedded G-Type Aluminum Finned Tube / Tubo Aletado and we sell this fin tubes in over 70countries.

We can handle kinds of projects in various industries, such as heat exchanger / boiler projects, marine projects, oil & gas projects etc in petroleum industry,power industry,chemical industry and heat service systems,etc.

Fin tubes have a finned surface, which increases their surface area and allows them to transfer heat more efficiently. Because of that,this makes them ideal for applications where high heat transfer rates are required.

Embedded G type Finned Tube provides a perfect connection between the fin and the tubes . The main design is that through professional equipment groove the tubes and fin insert fins into the helical groove. Finally combined the fin and tubes as intergral.Embedded Fin tubes can be used in higher temperatures and are very durable and they are best suited for the usages that involve high thermal cycling or high temperatures and where the fin side will be subjected to regular cleaning .

Features Of G-Type Embedded Finned Tube

Easy installation

High-performance

Less space required

Optimized surface

Less energy consumption

Increased reliability

Low maintenance

High mechanical resistance

Compact design

Average corrosion protection

Finest technology used

Specifications For Various Types We Can Offer

Type	Description	Base tube	Fin specification (mm)
Type	Description	O.D. (mm)	Fin pitch	Fin height	Fin thick
Embedded	G-type fin tueb	16-63	2.1~5	<17	~0.4
Extruded	Single metal combined metal	8-51	1.6~10	<17	0.2-0.4
	Low fin tube t-type fin tube	10-38	0.6~2	<1.6	~0.3
	Bamboo tube corrugated tube	16-51	8.0~30	<2.5	/
Wound	l/kl/ll type fin tube	16-63	2.1~5	<17	~0.4
String	String fin tube	25-38	2.1-3.5	<20	0.2-0.5
U-type	U-type tube	16-38	/	/	/
Welding	HF-welding fin tube	16-219	3~25	5~30	0.8-3
	H/HH type fin tube	25-63	8~30	<200	1.5-3.5
	Studed fin tube	25-219	8~30	5~35	φ5-20

Base Tube Material : Stainless Steel, Carbon Steel, Alloy Steel, Titanium, Copper, Duplex Stainless Steel, Inconel etc.

(all material in the theoretical limit)

Fin General Material : Aluminum, Copper, etc.

Detailes Of ASTM A179 Tube

ASTM A179 this specification covers minimum-wall-thickness, seamless cold-drawn low-carbon steel tubes for tubular heat exchangers, condensers, and similar heat transfer apparatus.Tubes shall be heat treated after the final cold draw pass at a temperature of 1200°F(650℃ )or higher.

Chemical Composition (%)

Grade	C	Mn	P	Su
A179	0.06-0.18	0.27-0.63	0.035, max	0.035, max

Mechanical Properties

Grade	Tensile Strength,min	Yield Strength (0.2%Offset,min)	Elongation
A179	ksi-47,MPa-325	psi-26,MPa-180	35%

Application

Steam Coils

Air Perheaters / Air Cooling Heat Exchanger

Air Coolers / Oil Coolers / Hydrogen Coolers / Generator Coolers

Waste Heat Recovery

Air Conditioning / Air Heaters

Boiler / Steam Condensers

Heat Pipe Technology
